Grade 2 Titanium Plates
2. Size: thickness 0.8-100mm * Width <2500mm * Length <6000mm
3. Standard: ASTM B265 ASME SB265 ASTM F67
4: Application:Industrial,Medical,Aerospace, Architectural,chemical processing,marine service,Power generation,Pulp and paper, petrochemicals, seawater desalination
Etermetal supply various kinds of custom shapes of commercial pure grade 2 titanium plates for industrial and medical application. We have 20 tons + Grade 2 titanium sheets in stock from thickness 0.8mm to 25mm for fast delivery. Linear cutting, laser cutting, water cutting, shear cutting enable us offer any make to order plates according to client's drawing or dimensions.
Grade 2 titanium is the most common and widest used titanium in industry as it is with high strength, good corrosion resistance and ductility. What's more, it is very easy to machine and bend. It's the best choice for many industrial applications not only because of it's property, but also it's economical price. Etermeal can use grade 2 titanium plates cut into rings, discs, or drill into tube plate for industrial use according to client's request. We will work with clients and happy to work with clients.
Gr2 titanium plates are nonmagnetic and bio-compatible. They are also welcomed for medical use. The plates can be used in dental, surgical implants, etc.
Here below are the gr2 titanium sheets available from Etermetal.
| commercial name | standard | size | application |
| grade 2 titanium plates | ASTM B265 ASME SB265 ASTM F67 |
thickness from 0.8mm to 300mm width below 2500mm length below 6000mm |
Industrial Medical Aerospace Architectural chemical processing marine service Power generation Pulp and paper petrochemicals seawater desalination |
The chemical composition of grade 2 titanium sheets (weight %)
| Fe | O | C | N | H | Ti |
| 0.03 | 0.25 | 0.08 | 0.03 | 0.015 | Balance |
Properties of gr2 titanium plates in room temperature
| Tensile strength | 345Mpa (50ksi) Min. |
| Yield strength | 275 Mpa (40ksi) Min. |
| Elongation(%) | 20 Min. |
| Working temperature | can be as high as 425℃ (continuous) - 540℃ ( intermittent) |
As the gr2 titanium plates are always used to produce large containers, most clients are care about what kind of material can be used to weld grade 2 titanium sheets? Usually it is better use the grade 2 titanium filler to weld grade titanium plates. And a variety of welding procedures can be using, such as gas tungsten arc welding, argon arc welding, plasma arc welding, etc.
Grade 2 titanium plates are not as hard as stainless steel. If you'd like to machine gr2 titanium sheets, you'd better use lower speed and make sure the cutting tools are sharp.
Inspection:
Certificates:
Packing:
For more information, please feel free contact us . We will reply you within 24 hours.
